6-Port 10/100M PoE+ Switch, Model: FS1006P -
6-Port 10/100M PoE+ Switch, Model: FS1006P -
Stokta yok
SKU:FS1006P
Teslim alım stok durumu yüklenemedi
● Complies with IEEE802.3af/at Standard
● Supports PoE power up to 32W for each PoE port
● Auto detect non PoE device and PoE device
● Power prioritization guarantee power supply of key nodes
● CCTV/VLAN mode switch, remote power and data up to 250m
● Supports IEEE802.3 x full duplex / half duplex flow control
● Supports storage and forward for Data exchange
 |
 |
 |
|
60W Power budget & 30W Maximum One Port Supports 60W total PoE power and up to 30W for one PoE port.Auto detect power device; will not burned non-standard PoE device or normal PoE switch. Complies with IEEE802.3af/at Standard |
Rack Mount & Wall Mount & Desktop ● Provide a variety of installation methods for easy deployment in any environment ● Support Wall mount installation ● Support Desktop installation |
Plug&Play, Fanless design Plug and Play, Easy of use.Fanless design for silent operation.Made of high-quality metal case, sturdy and durable with long service life, provide better heat dissipation, suitable for most environment. Pin assignment, Mode A: 1/2(+),3/6(-) |
 |
 |
 |
|
Surveillance Works with IP Cameras for home and office, small business |
VoIP Conference Call Works with VoIP phones for business conference |
Wi-Fi Coverage Works with WiFi APs for office and business |
Specifications
| Model | FS1006P |
| Network Protocol | IEEE802.3 / IEEE802.3u IEEE802.3x / IEEE802.3af/at |
| PoE standard | IEEE802.3af/at |
| Interface | 6*10/100Mbps RJ45 port |
| POE port output | DC 52V |
| PoE port | 1-4 |
| AC Input Voltage | AC100~240V |
| Power supply | 65W |
| Power Pin | Power over spare pairs 1/2(+) , 3/6 (-) |
| PoE output-port | Max 30W |
| MAC Address | 1K MAC address table |
| Packet buffer | 448K bit |
| Transfer Mode | Store-and-forward |
| Bandwidth | 1.2Gbps |
| Fan | Fanless |
| Device Dimension | 200mm*120mm*45mm |
| Machine weight | <1kg |
| Operating Temperature | -20°C ~ 50 °C |
| Storage Temperature | -40 °C ~ 80 °C |
| Operating Humidity | 10% ~ 90% non-condensing |
| Storage Humidity | 5% ~ 90% non-condensing |
